Structural redundancy is included in modern data transmission systems to ensure the specified reliability indicators. Structural redundancy gives the system fault tolerance and significantly increases its reliability. To manage the redundant resource, it is necessary to have additional tools that will connect the redundant equipment to the main configuration of the data transmission system. The redundant equipment is a separate technical means and, from the point of view of reliability, it is connected in series with other modules of the data transmission system. Thus, the inclusion of redundant connection facilities in the data transmission system reduces its reliability. In addition, even with perfect reliability, redundant connections may fail or malfunction and, under certain conditions, cause the transmission system to fail. To determine the impact of reserve connection facilities on the reliability of the transmission system, the article applies an original technology for building models of discrete-continuous stochastic systems. ASNA software was used as a software tool for modeling the reliable behavior of the data transmission system. This software provides automated construction of the model in the form of a graph of states and transitions based on a structural automaton model. Based on the graph of states and transitions, an analytical model is automatically generated in the form of a system of linear differential Kolmogorov-Chapman equations. Using the developed model, the article quantitatively analyzes the impact of redundant connection means (switches) on the reliability indicators of the data transmission system. In the study, the proposed models, unlike the existing ones, take into account both reliability indicators (probability of failure) and functionality indicators (probability of switching, speed) of the reserve connection means. On the basis of the developed model, the limit values of reliability and functionality of the redundant connection means (switches) were determined, at which they will minimize the reliability of the fault-tolerant data transmission system. Based on the analysis of the obtained results, practical recommendations for the selection of reliability indicators of the backup connection means, their speed and probability of switching are formed.
[1] David J Smith, (2022) Reliability, Maintainability and Risk. Practical Methods for Engineers, Tenth Edition, 2022, 496 p.
[2] Dongdong Chen, Long Xiao, Hemiu Lian, Zhenming Xu, (2021)“A fault tolerance method based on switch redundancy for shunt active power filter”, Energy Reports, Volume 7, Supplement 1, 2021, Pages 449-457
[3] Israel Koren, C. Mani Krishna (2007) Fault tolerant systems, Morgan Kaufmann Publishers is an imprint of Elsevier, 2007, 378 p.
[4] Pham H. (2003) Handbook of Reliability Engineering, London: British Library Cataloguing in Publication Data, 2003, 696 p.
[5] Величко Н.І. (Керівник – Озірковський Л.Д.) (2023) Оцінювання впливу засобів підключення резерву на показники надійності відмовостійких програмно-апаратних пристроїв. Бакалаврська кваліфікаційна робота, Львів, Національний університет «Львівська політехніка», 2023, 81с.
[6] https://www.wti.com/pages/effective-power-redundancy-solutions-to-minimi...
[7] Ryabtsev, V., Evdokimov, A., Almadi M., (2018)"Microprocessor Matrix Switcher for Diagnosing Digital Systems on Single Crystal," 2018 International Conference on Industrial Engineering, Applications and Manufacturing (ICIEAM),2018, pp. 1-5
[8] N. Wainstein, G. Adam, E. Yalon and S. Kvatinsky, (2021) “Radiofrequency Switches Based on Emerging Resistive Memory Technologies - A Survey”, Proceedings of the IEEE, vol. 109, no. 1, pp. 77-95, Jan. 2021
[9] Redundancy in KVM extenders and matrix switches. Technology briefing (2013), IHSE GmbH, Germany, August 2013 (https://www.ihse.de/wp-content/uploads/files/technology-briefings/ihse-t...)
[10] M:N Redundancy Switch Installation and Operation Manual. (2013) Part Number MN-RCS20, Revision 15, Comtech EF Data, 2013 (https://www.comtechefdata.com/files/MN-RCS20_15_10-18.pdf)
[11] https://www.quintechelectronics.com/applications/government-military.html
[12] Ю.Я. Бобало, Б.Ю. Волочій, О.Ю. Лозинський, Б.А. Мандзій, Л.Д. Озірковський, Д.В. Федасюк, С.В. Щербовських, В.С. Яковина, (2013) Математичні моделі та методи аналізу надійності радіоелектронних, електротехнічних та програмних систем. Монографія, Львів: Видавництво Львівської політехніки, 2013, 300 с.
[13] Bohdan Volochiy, Bohdan Mandziy, Leonid Ozirkovskyy, (2012) “Extending The Features of Software For Reliability Analysis of Fault-tolerant Systems”, Computational Problems of Electrical Engineering, Lviv Politechnic National University, 2012. - Volume 2, number 1, p. 113-121
[14] Безопасность критических инфраструктур: математические и инженерные методы анализа и обеспечения (2011), Под ред. Харченко В.С., Национальный аэрокосмический университет им. Н.Е. Жуковского "ХАИ", 2011, 641 с.
[15] Mustafa M. Alidrisi (1992) “The reliability of a dynamic warm standby redundant system of n components with imperfect switching”, Microelectronics Reliability, Volume 32, Issue 6, 1992, Pages 851-859
[16] Lun Ran, Jinlin Li, Xujie Jia, Hongrui Chu,(2014) “Optimal redundancy allocation for reliability systems with imperfect switching”, Journal of Systems Engineering and Electronic, Vol. 25, No. 2, April 2014, pp.332–339
